凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.XX[10]) - FRONT AUGER SADDLE MANUAL 435/460 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
318 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
GL-494
|
[1] |
ARM
|
FLX
Front Auger Lock
|
| 2. |
412427
|
[1] |
BOLT,Hex, M20 x 2.5 x 130mm, Cl 8.8
|
NH
|
| 3. |
87682419
|
[2] |
|
NUT
|
| 4. |
47744202
|
[1] |
SUPPORT
|
SAS
Front Auger Sadle
|
| 5. |
GL-791
|
[1] |
HEADLESS PIN
|
FLX
Low Auger Support Large
|
| 6. |
136065
|
[6] |
WASHER
|
NH
Flat
|
| 7. |
1312
|
[4] |
WASHER,1 9/32" x 2" x .120"
|
FLX
Superseded by part number: 86632583
|
| 8. |
87343
|
[4] |
LOCK PIN,6.35mm OD x 44.45mm L, Slotted
|
GI
|
| 9. |
GL-792
|
[1] |
HEADLESS PIN
|
FLX
|
| 10. |
47744213
|
[1] |
LINKAGE
|
SAS
Front Auger
|
| 11. |
11122521
|
[2] |
BOLT,Hex, M18 x 80, 8.8
|
MKT
Superseded by part number: 11122524
|
| 12. |
86900355
|
[2] |
NUT,M18 x 2.5, Cl 8
|
PA
|
| 13. |
86511191
|
[4] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 14. |
47744210
|
[1] |
SUPPORT
|
SAS
Front Auger
|
| 15. |
3419
|
[1] |
CAP
|
FLX
Vinyl
|
| 16. |
CA-218
|
[1] |
CLAMP
|
FLX
Auger Tube
|
| 18. |
47414111
|
[1] |
STOP
|
SAS
Auger Handle
|
| 19. |
GL-253-01
|
[1] |
BRACKET
|
SAS
Spring
|
| 20. |
87016607
|
[2] |
WASHER,13.5mm ID x 37mm OD x 3mm Thk
|
PLO
|
| 21. |
47744216
|
[1] |
HANDLE
|
SAS
Auger Latch Painted Black
|
| 22. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 23. |
323238
|
[1] |
THIN NUT,Hex, M12, 1.75mm Pitch, Cl 05
|
ZED
|
| 24. |
87506268
|
[1] |
COIL SPRING
|
SAS
Extension
|
| 25. |
1958265C1
|
[1] |
GRIP
|
CON
Vinyl Handle
|
| 26. |
86508581
|
[1] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
