| 1. |
47747646
|
[1] |
MOUNT
|
SAS
Manual Auger Black Superseded by part number: 47950744
|
| 2. |
47748216
|
[1] |
ARM
|
SAS
Auger Inner Superseded by part number: 47950737
|
| 3. |
47839650
|
[1] |
SUPPORT
|
SAS
Auger T
|
| 4. |
47745126
|
[1] |
MOUNT
|
SAS
Auger Latch
|
| 5. |
84557601
|
[1] |
PIN,31.75mm OD x 442mm L
|
SAS
|
| 6. |
23261
|
[2] |
WASHER
|
SAS
1.515 ID 2.25"
|
| 7. |
43168
|
[2] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 8. |
323866
|
[4] |
BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8
|
NH
Superseded by part number: 120091
|
| 9. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 10. |
47534143
|
[2] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
|
| 11. |
146988
|
[14] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 12. |
47748656
|
[1] |
ROD
|
SAS
Auger Arm 350 Superseded by part number: 47950747
|
| 13. |
130078
|
[1] |
LOCK PIN,M4 x 30, Slotted
|
COE
Superseded by part number: 14164370
|
| 14. |
87505489
|
[1] |
COMPRESSION SPRING
|
SAS
|
| 15. |
9706717
|
[2] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
NH
|
| 16. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 17. |
86518210
|
[1] |
BOLT,Hex, M14 x 75mm, Cl 8.8
|
BAS
|
| 18. |
412370
|
[1] |
NUT,M14 x 2, Cl 8
|
ZED
|
| 19. |
87020818
|
[1] |
LOCK PIN,1/4" OD x 2" OAL, Slotted
|
EML
|
| 20. |
84583373
|
[1] |
SUPPORT
|
SAS
Hose Guide Swivel
|
| 21. |
47839837
|
[1] |
LUG
|
SAS
Auger Pivot
|
| 22. |
86624086
|
[1] |
PIN,5/8" x 3", Coiled
|
FOR
|
| 23. |
47744192
|
[1] |
SUPPORT
|
SAS
Auger Rear
|
| 24. |
47744197
|
[1] |
SUPPORT
|
SAS
Auger Rear
|
| 25. |
1313
|
[2] |
WASHER,1-1/2" ID x 2-1/4" OD x 10 Ga Thk
|
FLX
Superseded by part number: 81900328
|
| 26. |
86585176
|
[1] |
LUBE NIPPLE,90 Degree, 1/4" NPT x .75" lg
|
GI
Superseded by part number: 87415
|
| 27. |
80714
|
[1] |
LUBE NIPPLE,1/4"-28 NPT x .54" lg
|
PA
Superseded by part number: 87414
|
| 28. |
381928
|
[2] |
ROLL PIN,10mm OD x 50mm L, Slotted
|
ZED
|
