| 1. |
47455696
|
[1] |
MOUNT
|
SAS
Auger Black
|
| 2. |
47455699
|
[1] |
ARM
|
SAS
Auger Inner
|
| 3. |
47455683
|
[1] |
MOUNT
|
SAS
Inner
|
| 4. |
84573233
|
[1] |
BUSHING
|
SAS
|
| 5. |
86624169
|
[2] |
WASHER,1.03" ID x 1.5" OD x 0.06" Thk
|
FOR
|
| 6. |
87418581
|
[1] |
PIN,25.4mm OD x 104mm L
|
SAS
|
| 7. |
6392
|
[2] |
SNAP RING,#98, Ext
|
SAS
Superseded by part number: 87019495
|
| 8. |
87613202
|
[3] |
WASHER,1.03" ID x 2" OD x 0.06" Thk
|
BRR
|
| 9. |
84534942
|
[1] |
WASHER,25.8mm ID x 51mm OD x 14mm Thk
|
SAS
|
| 10. |
280346
|
[1] |
BOLT,Hex, 1"-8 x 5 1/2", G5
|
GI
Superseded by part number: 413-1688
|
| 11. |
280286
|
[1] |
NUT,1"-8, GB
|
NH
|
| 12. |
9706717
|
[2] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
NH
|
| 13. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 14. |
84557601
|
[1] |
PIN,31.75mm OD x 442mm L
|
SAS
|
| 15. |
87301770
|
[2] |
BOLT,Hex, 9/16" - 12 x 3-1/4", Gr 8
|
SAS
|
| 16. |
6035
|
[2] |
LOCK NUT,Hex, 9/16" - 12, Gr 8
|
SAS
Superseded by part number: 280328
|
| 17. |
84384075
|
[1] |
PIN,31.75mm OD x 342mm L
|
SAS
|
| 18. |
323866
|
[11] |
BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8
|
NH
Superseded by part number: 120091
|
| 19. |
43168
|
[2] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 20. |
47534143
|
[1] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
|
| 21. |
140020
|
[5] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 22. |
146988
|
[15] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 23. |
47455684
|
[1] |
LINKAGE
|
SAS
Arm Inner Black
|
| 24. |
47622462
|
[1] |
UPPER LINK
|
SAS
Parallel Arm
|
| 25. |
84527313
|
[1] |
LINK
|
SAS
Lower
|
| 26. |
84527314
|
[1] |
LINK
|
SAS
Outer
|
| 27. |
84384034
|
[1] |
BAR
|
SAS
Auger T
|
| 28. |
84527316
|
[1] |
CLEVIS
|
SAS
Auger Pivot
|
| 29. |
84536100
|
[1] |
STOP
|
SAS
Auger Pivot
|
| 30. |
47630494
|
[1] |
HINGE
|
SAS
Hose Support
|
| 31. |
84384076
|
[4] |
PIN,25.4mm OD x 180mm L
|
SAS
|
| 32. |
86632585
|
[1] |
WASHER,1.53" ID x 2.25" OD x 0.06" Thk
|
FOR
|
| 33. |
86624086
|
[2] |
PIN,5/8" x 3", Coiled
|
FOR
|
| 34. |
9706693
|
[4] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 35. |
86508581
|
[1] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 36. |
47614289
|
[1] |
SUPPORT
|
SAS
Cam Arm
|
| 37. |
47614291
|
[1] |
SLIDER
|
SAS
Cam Arm
|
| 38. |
47614297
|
[1] |
SLIDER
|
SAS
Cam Arm
|
| 39. |
300351
|
[5] |
SCREW,Hex Flat Hd, M8 x 30, 4.8
|
PA
|
| 40. |
68841
|
[5] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
