神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (11-026) - MOTOR ASSY (PROPELLING)- 2441U739 F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
109 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U739F2 | [1] | ENGINE | KOB(PROPELLING), CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2441U739F3 |
| 1. | 2441U739S1 | [1] | SHAFT | KOB |
| 2. | 2441U739S2 | [1] | BALL BEARING | KOB Superseded by part number: 25T816D10 |
| 3. | 2441U739S3 | [1] | BEARING | KOBBEARING |
| 4. | 2441U739S4 | [1] | CONTROL BLOCK | KOBCOVER |
| 5. | 2441U739S5 | [1] | SEAL KIT | KOB |
| 6. | ZD12G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 7. | ZR26X11500 | [1] | SNAP RING | KOB |
| 8. | 2441U739S8 | [1] | BELT CASING | BELT CASING |
| 9. | 2441U739S9 | [1] | BLOCK | KOBCYLINDER-BLOCK |
| 10. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONSHOE, RETAINER |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONJOINT, BALL |
| 13. | 2441U739S13 | [1] | SPRING | KOB |
| 14. | 2441U739S14 | [1] | SPRING SEAT | KOB |
| 15. | ZR26X07200 | [1] | SNAP RING | KOB |
| 16. | 2441U739S16 | [3] | PIN | KOBPIN, RETAINER |
| 17. | 2441U739S17 | [1] | HOLDER | KOBRING |
| 18. | 2441U739S18 | [1] | SPRING SEAT | KOB |
| 19. | 2441U739S19 | [4] | CLUTCH PLATE | KOB |
| 20. | 2441U739S20 | [5] | STEP PLATE | KOB |
| 21. | 2441U518S30 | [14] | SPRING | KOB |
| 22. | 2441U739S22 | [1] | PISTON | KOBPISTON |
| 23. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, SHOE |
| 24. | NSS | [2] | NOT SOLD SEPARAT | CONPIVOT |
| 25. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 26. | ZD12P00900 | [6] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 27. | 2441U739S27 | [1] | COVER | |
| 28. | ZD12G22000 | [1] | O-RING,219.30mm ID x 230.70mm OD x 5.70mm | KOB |
| 29. | 2441U739S29 | [2] | PIN | KOB |
| 30. | 2441U739S30 | [1] | PLATE | KOBVALVE |
| 31. | 2436R658 | [3] | POPPET | KOBVALVE, RESTRICTOR |
| 32. | 2438U223S4 | [3] | SPRING | |
| 34. | 2441U739S34 | [1] | SPACER | KOB |
| 35. | ZR16X06000 | [1] | RING | KOB |
| 36. | 2441U739S36 | [1] | RACE | KOBCOLLAR |
| 37. | 2441U739S37 | [1] | PISTON RING | KOB |
| 38. | 2441U739S38 | [1] | PISTON RING | KOB |
| 39. | 2441U739S39 | [1] | PISTON RING | KOB |
| 40. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 41. | 2441U739S41 | [1] | STOP | KOB |
| 42. | 2441U739S42 | [3] | BOLT | KOB |
| 43. | ZS23C18065 | [4] | SCREW,Hex Socket Head, M18 x 65mm | KOBM18x2.50x65mm |
| 44. | ZS23C18055 | [6] | SCREW,Hex Socket Head, M18 x 55mm | KOBM18x2.50x55mm |
| 45. | 2436U1139S10 | [3] | PLUG | KOB |
| 46. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 47. | 2483U171S34 | [2] | PLUG | KOB |
| 48. | 2441U739S48 | [1] | RING | KOB |
| 49. | ZD12P00700 | [1] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 50. | 2436U1123S14 | [1] | ORIFICE | KOBORIFICE |
| 51. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 52. | 2436R760F1 | [2] | VALVE | KOBASSY, RELIEF, SEE FIGURE 11-007 |
| 53. | 2436U1301F1 | [1] | PILOT VALVE | KOBASSY, SEE FIGURE 11-015 |
| . . | 2441U739R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF 10 |
| . . | 2441U739R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF 11, 12 |
| . . | 2441U739R300 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF 23 - 25 |
