神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (11-027) - MOTOR ASSY (SWING)- 2441U758 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U758F1 | [1] | MOTOR | KOBASSY (SWING), CONSISTS OF THE FOLLOWING PARTS |
| 012. | 2441U758S12 | [9] | PISTON ASSY, CONSISTS OF REF 121, 122 | |
| 013. | 2441U549S13 | [1] | CYLINDER | KOBASSY, CONSISTS OF REF 111, 131 |
| 018. | 2441U758S18 | [1] | REPAIR KIT | KOBPLATE ASSY, CONSISTS OF REF 113, 123 |
| 020. | 2441U549S20 | [1] | KIT | KOBCOVER ASSY, VALVE, CONSISTS OF REF 303, 451 |
| 023. | 2441U758S23 | [1] | REPAIR KIT | KOBCOVER ASSY, FRONT, CONSISTS OF REF 304, 452 |
| 031. | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOBASSY, REDUCTION, SEE FIGURE 11-013 |
| 101. | 2441U758S101 | [1] | SHAFT | KOB |
| 106. | 2415U164S510 | [1] | SPACER | SPACER |
| 107. | 2441U758S107 | [1] | SPACER | |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 113. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 114. | 2441U722S157 | [4] | SPRING CONED DISK | SPRING CONED DISK |
| 115. | 2441U722S158 | [1] | SHIM | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 124. | 2441U564S124 | [1] | PLATE | KOB |
| 131. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE |
| 133. | 2441U722S315 | [1] | GUIDE RING | KOBRING, GUIDE |
| 301. | 2441U758S301 | [1] | BELT CASING | BELT CASING |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE |
| 304. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, FRONT |
| 401. | ZS23C10085 | [3] | SCREW,Hex Socket Head, M10 x 85mm | KOBM10x1.50x85mm |
| 402. | ZS23C10040 | [9] | SCREW,Hex Socket Head, M10 x 40mm | KOBM10x1.50x40mm |
| 403. | ZS23C12030 | [8] | SCREW,Hex Socket Head, M12 x 30mm | KOBM12x1.75x30mm |
| 431. | 2441U242S825 | [2] | RING, STOP | RING, STOP |
| 437. | ZR26X11000 | [1] | LOCKING RING | KOB |
| 443. | 2441U549S443 | [1] | ROLLER BEARING | KOB |
| 444. | 2441U703S444 | [1] | BEARING | BEARING |
| 451. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 452. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 464. | 2441U436S468 | [1] | PLUG | KOB |
| 472. | 2441U168S19 | [1] | O-RING | KOB |
| 474. | 2453U139S28 | [1] | O-RING | KOB |
| 485. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 491. | 2441U556S491 | [1] | OIL SEAL | KOB Superseded by part number: R45P0031D3 |
| 702. | 2441U758S702 | [1] | PISTON | KOB |
| 703. | 2441U758S703 | [1] | COUPLING | |
| 706. | 2441U736S706 | [1] | O-RING | KOB |
| 712. | 2441U758S712 | [2] | SPRING | KOBCONED DISK |
| 713. | 2441U758S713 | [1] | SEAT, SPRING | SEAT, SPRING |
| 714. | 2441U758S714 | [1] | SEAT, SPRING | SEAT, SPRING |
| 715. | 2441U758S715 | [1] | SHIM | SHIM |
| 742. | 2441U758S742 | [1] | PLATE | KOB |
| 992. | ZE82T08000 | [2] | PLUG | KOB1/2" PT |
