神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (11-028) - FILTER ASSY- 2446U233 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
991 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2446U233F1 | [1] | FILTER ASSY | KOBCONSIST OF THE FOLLOWING PARTS |
| 1. | 2446U232S1 | [1] | COVER | KOB |
| 2. | 2446U233S2 | [1] | ELEMENT | KOBASSY |
| 3. | 2446U232S3 | [1] | CASE | KOB |
| 4. | 2446U233S4 | [1] | PLUG | |
| 5. | 2446U233S5 | [1] | VALVE | |
| 6. | 2446U233S6 | [1] | SPRING | |
| 7. | 2446U233S7 | [1] | PLUG | KOB |
| 8. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 9. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm |
| 10. | ZD11P05000 | [1] | O-RING | KOB |
| 11. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 12. | 2446U233S12 | [1] | SCREW | KOB |
| 13. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
