凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.XX[19]) - DELUXE AUGER HOPPER Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 847 次

Pos.	Part No	Qty	Parts name	Comments
1.	47410045	[1]	HOPPER	SAS Auger Deluxe
2.	47782500	[1]	COVER	SAS Access
3.	88542	[4]	BOLT,Hex, 1/4"-20 x 1/2", Gr 5	NH
4.	84383971	[1]	SHEET	SAS Ruber
5.	84384066	[1]	AUGER FLIGHT	SAS Hopper
6.	84418242	[1]	BEARING ASSY	SAS
7.	88966	[2]	BOLT,Hex, 1/2" - 20 x 4", Gr 8	GI
8.	87333768	[2]	NUT,1/2" - 20	GI
9.	9549	[1]	FLANGED BEARING	FLX 2 Hole Superseded by part number: 50591, 84330070, 47577183
10.	280497	[2]	CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd	NH
11.	86629544	[2]	NUT,5/16” – 18, GR B	NH Superseded by part number: 280736
12.	84383978	[1]	GRATE	SAS Auger Coarse
13.	81821889	[1]	BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd	BAS Superseded by part number: 280643
14.	47392035	[1]	SECURING STRAP	SAS Hopper End
15.	47392031	[2]	SECURING STRAP	SAS Side
16.	87657	[12]	BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5	NH
17.	9635082	[12]	NUT,5/16" - 18, Gr 5	NH
18.	88206	[8]	BOLT,Hex, 3/8" - 16 x 1", Gr 5	NH
19.	9637692	[9]	NUT,3/8"-16, GB	NH
20.	47392036	[1]	COVER	SAS Hopper
21.	87016	[9]	WASHER,0.41" ID x 0.81" OD x 0.07" Thk	NH
22.	47408276	[1]	DOOR	SAS
23.	47411825	[1]	CLIP	SAS Door Left
24.	47428381	[1]	CLIP	SAS Door Right
25.	47411827	[1]	LATCH	SAS Cleanout Door
26.	88011	[1]	BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5	NH
27.	84497405	[1]	GEARBOX	SAS Drive
28.	84527686	[1]	GUIDE	SAS Auger Coupler
29.	84424480	[1]	DRIVE	SAS Auger Coupler
30.	281069	[2]	BOLT,Hex, 1/4" - 20 x 2 1/2", Gr 8	GI
31.	20356	[2]	NUT,1/4"-20, GB	PA Superseded by part number: 280129
32.	84424488	[2]	KEY	SAS
