| 1. |
47741731
|
[1] |
FRAME
|
SAS
Feeder Housing
|
| 2. |
47741903
|
[1] |
ROTOR
|
SAS
|
| 3. |
47741936
|
[1] |
FRAME
|
SAS
Feeder End Cap
|
| 4. |
47879567
|
[1] |
PLENUM
|
SAS
Aux Fill
|
| 5. |
47807674
|
[1] |
MANIFOLD
|
SAS
Tank Fill Black
|
| 6. |
47798540
|
[1] |
MOUNT
|
SAS
Rotary Feeder Black
|
| 7. |
48047789
|
[1] |
Meter Drive
|
HYDRAULIC MOTOR
|
| 8. |
47738083
|
[1] |
TANK
|
SAS
Hopper
|
| 9. |
47874543
|
[1] |
COUPLING
|
SAS
Rotary
|
| 10. |
47742985
|
[4] |
VENTURI
|
SAS
Fill System
|
| 11. |
47807435
|
[1] |
PLATE
|
SAS
Aux Fill Seal Black
|
| 12. |
47812220
|
[2] |
LATCH
|
SAS
Adjustable Draw
|
| 13. |
47880914
|
[2] |
SEAL
|
SAS
|
| 14. |
353308
|
[34] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 15. |
120100
|
[23] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 16. |
86625162
|
[4] |
SELF-TAP SCREW,HWH, 1/4" - 14 x 1/2"
|
PA
|
| 17. |
47798809
|
[2] |
SHIELD
|
SAS
Feeder Motor
|
| 18. |
47808306
|
[1] |
COVER
|
SAS
Feeder Shaft
|
| 19. |
47812267
|
[1] |
COVER
|
SAS
Fill Hopper Superseded by part number: 47929281
|
| 20. |
47810403
|
[1] |
ROD
|
SAS
Hopper Pivot
|
| 21. |
9549
|
[2] |
FLANGED BEARING
|
FLX
Superseded by part number: 50591, 84330070, 47577183
|
| 22. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 23. |
68841
|
[4] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
| 24. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
|
| 25. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 26. |
47743839
|
[1] |
SEAL
|
SAS
Rottarty Feeder Pump
|
| 27. |
47770130
|
[2] |
SUPPORT
|
SAS
Deflector
|
| 28. |
47763156
|
[1] |
|
|
| 29. |
BRR1768926
|
[4] |
SCREW,Hex, M6 x 1 x 110mm, Cl 8.8
|
BRR
|
| 30. |
9706703
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 31. |
43118
|
[1] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 32. |
6244
|
[3] |
BOLT,Hex, 1/4" - 28 x 1/2", Gr 5, Full Thd
|
SAS
Superseded by part number: 80280640
|
| 33. |
2292390
|
[2] |
BOLT,Hex, M6 x 125mm, Cl 8.8
|
BRR
Superseded by part number: BER2292390, BER2292390, BRR2292390
|
| 34. |
6854
|
[2] |
PIN
|
FLX
|
| 35. |
280236
|
[4] |
COTTER PIN,1/16" x 1/2"
|
WIN
|
| 36. |
86624182
|
[2] |
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
|
FOR
|
| 37. |
43645
|
[6] |
SCREW,Hex Flat Hd, M4 x 12, 4.8
|
WIN
|
| 38. |
152799
|
[6] |
NUT,Prev Torque, Hex, M4 x 0.7, Cl 5
|
BER
Superseded by part number: 515961
|
| 39. |
86632577
|
[1] |
SET SCREW,Hex Skt, 1/4" - 20 x 1/4"
|
FOR
|
| 40. |
218-5370
|
[2] |
HYD CONNECTOR,7/16"-20, 37 Degree x 3/8"-24, O-Ring
|
CAS
Auxilary Feeder Hopper
|
| 41. |
47433182
|
[1] |
DECAL
|
SAS
Chemical Hazard
|
| 42. |
87361
|
[1] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
