凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AF[01]) - PRESSURE SENSOR 4 BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
381 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47843564
|
[4] |
FITTING
|
SAS
Pressure Sensor Assy, Incl 2, 3, 5
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hose, Pressure Sensor, Incl with 1
|
| 4. |
47502736
|
[8] |
SENSOR
|
SAS
Pressure
|
| 5. |
513309
|
[4] |
HOSE CLAMP,1-1/16" - 2", Worm
|
NH
Incl with 1
|
| 6. |
47814496
|
[4] |
WIRE HARNESS
|
SAS
Tank/Metering Pressure, Incl 7 - 9
|
| 7. |
87700105
|
[1] |
ELEC CONNECTOR
|
BAS
X-235, Pressure
|
| 7. |
87696141
|
[4] |
TERMINAL
|
CUR
X-235, Pressure
|
| 8. |
47685860
|
[1] |
WIRE CONNECTOR
|
SAS
X-236, Pressure
|
| 8. |
84278796
|
[3] |
TERMINAL
|
SAS
X-236, Pressure
|
| 10. |
47908963
|
[1] |
TOOL
|
SAS
Drill Srepped
|
| 11. |
47908965
|
[1] |
TOOL
|
SAS
Tapered Start Tap M14 x 1.5mm
|
