纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (340-01[1]) - RING ASSY, SLEWING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT40F00005F1 | [1] | Ring Assy, Slewing | |
| 1. | YT40F00004F1 | [1] | RING | KOBAssy, Slewing |
| 1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONRace, Inner |
| 1-8. | YT40F00004S008 | [1] | SEAL | KOBSeal |
| 1-9. | YT40F00004S009 | [1] | SEAL | KOBSeal |
| 2. | ZS13C16085 | [30] | SCREW | KOBCap, Serial Range: LF05-04001-LF05-04277 |
| . . | YY52F01378P1 | [30] | SCREW | KOBCap, Start Serial: LF05-04278 |
| 3. | YT40F01002P1 | [1] | SEAL | KOB, Serial Range: LF05-04001-LF05-04132 Superseded by part number: YT40F01003P1 |
| . . | YT40F01003P1 | [1] | SEAL | KOB, Start Serial: LF05-04133 |
