纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (346-01[1]) - IDLER ASSY, CRAWLER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
167 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT52D00007F1 | [1] | Idler Assy, Crawler | |
| 1. | YT52D00006F1 | [2] | IDLER | KOBAssy, Crawler |
| 1-1. | YT52D00002F1 | [1] | IDLER | KOBAssy (See Fig NO. 356-01-1) |
| 1-2. | YT54D00002F1 | [1] | IDLER | KOBAdjust Assy (See Fig No. 360-01-1) |
| 1-3. | 2444P803 | [1] | LUBE NIPPLE,5/8” – 18 x 64mm L, 19mm Hex | KOBGrease |
| 1-4. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBCap |
