凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AJ[10]) - PLATFORM 350 BUSHELL TOW BEHIND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
353 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47453869
|
[1] |
PLATFORM
|
SAS
Corner Black
|
| 2. |
47458621
|
[1] |
SUPPORT
|
SAS
Corner Platform Black
|
| 3. |
47452211
|
[1] |
PLATFORM
|
SAS
Short Black
|
| 4. |
47484303
|
[1] |
PLATFORM
|
SAS
Short Black
|
| 5. |
47452194
|
[2] |
SUPPORT
|
SAS
Platform Black
|
| 6. |
47615824
|
[1] |
PLATE
|
SAS
Toe Kick End
|
| 7. |
47534143
|
[6] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
M16
|
| 8. |
146988
|
[12] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 9. |
47590160
|
[6] |
U-BOLT
|
SAS
M12
|
| 10. |
86511324
|
[12] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 11. |
100038
|
[30] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 12. |
9706687
|
[18] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
