凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AJ[11]) - PLATFORM HANDRAILS 350 BUSHELL TOW BEHIND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
770 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47615876
|
[1] |
HANDRAIL
|
SAS
Short Platform
|
| 2. |
47698290
|
[1] |
BRACKET
|
SAS
Mount Black With Decal Incl 3 - 4
|
| 3. |
84004732
|
[1] |
CAUTION DECAL
|
ZED
Caution
|
| 4. |
47433182
|
[1] |
DECAL
|
SAS
Chemical Hazard
|
| 5. |
352892A1
|
[2] |
U-BOLT
|
CAS
M8
|
| 6. |
68841
|
[4] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
| 7. |
47752946
|
[1] |
TUBE
|
SAS
Hatch Entry Support
|
| 8. |
8060
|
[1] |
CAP
|
FLX
Vinyl 1.5 X .75"
|
| 9. |
647695
|
[1] |
PIN,7.94mm OD
|
NH
|
| 10. |
47537957
|
[1] |
HANDRAIL
|
SAS
Short Plattform Black
|
| 11. |
47615369
|
[1] |
HANDRAIL
|
SAS
Front Black
|
| 12. |
47487633
|
[1] |
HANDRAIL
|
SAS
Platform Corner Black
|
| 13. |
47615895
|
[1] |
PLATFORM
|
SAS
Rail Black
|
| 14. |
47615901
|
[1] |
PLATFORM
|
SAS
Rail Black
|
| 15. |
43144
|
[20] |
BOLT,Hex, M10 x 70mm, Cl 8.8
|
NH
Superseded by part number: 87015537
|
| 16. |
86625253
|
[32] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 17. |
100037
|
[20] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
87574044
|
[4] |
PIN
|
SAS
|
