现代零件查询R55-7A BOOM CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
435 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-51110
|
[1] |
BOOM CYLINDER ASSY-LH
|
|
| . |
31M8-50111
|
[1] |
BOOM CYLINDER ASSY-RH
|
|
| 1. |
31Y1-23671
|
[1] |
TUBE ASSY-LH
|
|
| 1. |
31Y1-24511
|
[1] |
TUBE ASSY-RH
|
|
| 2. |
31Y1-22260
|
[1] |
ROD ASSY-LH
|
|
| 2. |
31Y1-24320
|
[1] |
ROD ASSY-RH
|
|
| 3. |
31Y1-22560
|
[1] |
GLAND
|
|
| 4. |
S731-065030
|
[1] |
BUSHING-DU
|
|
| K5. |
Y200-065011
|
[1] |
SEAL-ROD
|
|
| K6. |
Y180-065020
|
[1] |
RING-BACK UP
|
|
| K7. |
Y240-065011
|
[1] |
RING-BUFFER
|
|
| K8. |
Y110-065011
|
[1] |
WIPER-DUST
|
|
| 9. |
Y190-079000
|
[1] |
RING-SNAP
|
|
| K10. |
S632-110001
|
[1] |
O-RING
|
|
| K11. |
S632-105004
|
[1] |
O-RING
|
|
| K12. |
S642-105003
|
[1] |
RING-BACK UP
|
|
| K13. |
S631-100004
|
[1] |
O-RING
|
|
| K14. |
S641-100003
|
[2] |
RING-BACK UP
|
|
| 15. |
31YC-25030
|
[1] |
RING-CUSHION
|
|
| 16. |
31Y1-24300
|
[1] |
PISTON
|
|
| K17. |
S631-058004
|
[1] |
O-RING
|
|
| K18. |
S641-058003
|
[2] |
RING-BACK UP
|
|
| K19. |
Y450-110000
|
[1] |
SEAL-PISTON
|
|
| K20. |
Y300-110000
|
[1] |
RING-WEAR
|
|
| K21. |
Y440-110000
|
[1] |
RING-DUST
|
|
| 22. |
31YC-65350
|
[1] |
NUT-NYLON
|
|
| 23. |
31Y1-22870
|
[1] |
PIPE ASSY-R
|
|
| 24. |
31Y1-22881
|
[1] |
PIPE ASSY-B
|
|
| K25. |
Y171-019004
|
[1] |
O-RING
|
|
| 26. |
S107-100454
|
[4] |
BOLT-SOCKET
|
|
| 27. |
S011-100152
|
[2] |
BOLT-HEX
|
|
| 28. |
S403-102002
|
[2] |
WASHER-PLAIN
|
|
| 29. |
31YC-12110
|
[1] |
BUSHING-PIN
|
|
| 30. |
Y010-060075
|
[4] |
SEAL-DUST
|
|
| 31. |
S651-810002
|
[1] |
NIPPLE-GREASE
|
|
| 32. |
31YC-11535
|
[1] |
BUSH-PIN
|
|
| K. |
31Y1-24310
|
[1] |
SEAL KIT
|
|
