纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (450-01-1[1]) - BOOM GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
213 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01. | YT01V00030F1 | [2] | LIFT CYLINDER | KOBAssy, Boom |
| 02. | YT01V00031F1 | [1] | LIFT CYLINDER | KOBAssy, Arm |
| . . | LF02B00016F1 | [1] | Boom Group | |
| A1. | 2444R1117D090 | [1] | HOSE,6.40mm ID x 900mm L | KOB Superseded by part number: HX21E04090DY |
| A2. | ZG91V02000 | [1] | LUBE NIPPLE | KOBGrease |
| A3. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGrease |
| A4. | YR02B01035P1 | [1] | COVER | KOB |
| A5. | 2420T7541 | [1] | SCREW | KOBCap |
| A6. | 2417T539 | [1] | SPRING | KOB |
| A7. | ZW26X12000 | [1] | WASHER | KOB |
| A8. | 2418T22593 | [1] | WASHER | KOB |
| A9. | PY02B01064P1 | [2] | TUBE | KOB |
| A10. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| . . | LF02B00025F1 | [1] | Boom Assy, Hoe | |
| B1. | LF02B00026F1 | [1] | BOOM | KOBBoom Assy, Hoe [ see figure no.455-01-1 ] |
| B2. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust |
| . . | LF02B00004F1 | [1] | Boom Instal | |
| C1. | LF02B01006P2 | [1] | PIN | KOB |
| C2. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| C3. | 2418T21137 | [1] | WASHER | KOB |
| C4. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| C5. | YR02B01266D3 | [1] | SHIM | KOB(0. 5) |
| . . | LF02B00013F1 | [1] | Cylinder Instal | |
| . . | LF02B00014F1 | [1] | CYLINDER | KOBCylinder Instal |
| D1. | YT02B01220P1 | [1] | PIN | KOB |
| D2. | LF02B01008P1 | [1] | PIN | KOB |
| D3. | HS18C12125G2 | [1] | SCREW | KOBCap |
| D4. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| D6. | ZN18C12010 | [2] | NUT | KOB |
| D7. | YT02B01008D1 | [1] | SHIM | KOB(0. 5) |
| D8. | B16T0442D93 | [1] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOB(0. 9) |
| D9. | YT02B01008D2 | [1] | SHIM | KOB(1. 2) |
| D10. | YR02B01262P1 | [2] | SHIM | KOB(2. 0) |
| D11. | B16T0442D82 | [1] | SHIM,120mm OD x 77mm ID x 0.5mm Thk | KOB(0. 5) |
| D12. | B16T0442D81 | [1] | SHIM,120mm OD x 77mm ID x 0.9mm Thk | KOB(0. 9) |
| D13. | B16T0442D80 | [1] | SHIM,120mm OD x 77mm ID x 1.2mm Thk | KOB(1. 2) |
| D14. | YR02B01261P1 | [2] | SHIM,2mm Thk | KOB(2. 0) |
| . . | YT02B00087F1 | [1] | Cylinder Instal | |
| . . | YT02B00006F1 | [1] | CYLINDER | KOBInstal |
| E1. | YT02B01009P1 | [1] | PIN | KOB |
| E2. | HS18C12115G2 | [1] | SCREW,M12 x 115mm, Cl 10.9 | KOBCap |
| E4. | B16T0442D56 | [1] | SHIM,0.5mm Thk | KOB |
| E5. | B16T0442D43 | [1] | SHIM,0.9mm Thk | KOB |
| E6. | B16T0442D27 | [1] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOB(1. 2) |
| E7. | PY02B01028P1 | [2] | SHIM,2.0mm Thk | KOB |
