纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (455-01-1[1]) - BOOM ASSY, HOE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
456 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF02B00026F1 | [1] | BOOM | KOBBoom Assy, Hoe |
| 1. | LF02B00023F1 | [1] | BOOM | KOBBoom Assy, Hoe |
| 1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBoom, Hoe |
| 1-2. | YT02B01212P1 | [2] | BUSHING | KOB |
| 2. | LF02B00012P1 | [1] | BOOM | KOBBoom, Hoe (block) |
| 2-1. | YT12B01227P1 | [4] | BLOCK | KOBBlock, Tapped |
| 2-2. | YT02B01149P1 | [2] | BLOCK | KOBBlock, Tapped |
| 2-3. | LF02B01035P1 | [1] | BLOCK | KOBBlock, Tapped |
| 2-4. | HY35B10032G1 | [3] | BLOCK | KOBTapped |
| 2-5. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTapped |
| 2-6. | 2416T12922 | [2] | BLOCK | KOBTapped |
| 2-7. | 2418T23218 | [1] | PLATE | KOB |
| 2-8. | YT02B01146P1 | [2] | BRACKET | KOBBracket |
| 2-11. | YT02B01201P1 | [2] | BLOCK | KOBBlock, Tapped |
