纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (501-60-1[1]) - HYD LINES, BOOM (NIBBLER & BREAKER) 3. 67M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
912 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF42H00017F1 | [1] | Hyd Lines, Boom 3. 67m | |
| . . | LF42H00011F1 | [1] | PIPE | KOBHyd Lines, Boom [ see figure no.500-18-1,2 ] |
| . . | LF42H00012F1 | [1] | PIPE | KOBHyd Lines, Boom |
| A1. | LF42H01050P1 | [1] | TUBE | KOB |
| A2. | LF42H01051P1 | [1] | TUBE | KOB |
| A3. | ZE72X12000 | [2] | PLUG | KOB |
| A4. | YT43H01116P1 | [8] | CLAMP | KOB |
| A5. | LF42H01017P1 | [2] | CLAMP | KOB |
| A6. | ZC26X22011 | [2] | CLAMP | KOB |
| A7. | ZM73C10045 | [18] | BOLT,M10x45mm - Course Thread | KOBSems |
| A8. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBCap |
| A9. | ZW16H10000 | [2] | WASHER | KOB |
| . . | LF42H00020F1 | [1] | Hyd Lines, Boom | |
