纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (570-01-1[1]) - LIGHT INSTAL, BOOM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
942 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LE80E00002F1 | [1] | BOOM | KOBLight Instal |
| A1. | YN80S00012F1 | [1] | LIGHT | KOBAssy [ see figure no.572-01-1 ] Superseded by part number: 2456R442F1 |
| A2. | 2416T13056 | [1] | BRACKET | KOB |
| A3. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| A4. | 2418R323D11 | [1] | WASHER | KOB |
| A5. | 2418R323D13 | [1] | LOCK WASHER | KOB |
| . . | LF15E00004F1 | [1] | Harness Assy, Boom | |
| B1. | LF15E01003P1 | [1] | WIRE HARNESS | KOBHarness |
| B2. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOB |
