现代零件查询R55-7A QUICK CLAMP ASSY(HOOK TYPE 1)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
1004 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-95630
|
[1] |
QUICK CLAMP ASSY
|
|
| 1. |
XKBP-00147
|
[1] |
BODY ASSY
|
|
| 2. |
XKBP-00148
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBP-00149
|
[1] |
HOOK ASSY
|
|
| 4. |
XKBP-00150
|
[1] |
LOCK ASSY
|
|
| 5. |
XKBP-00151
|
[2] |
PIN-BRACKET
|
|
| 6. |
XKBP-00152
|
[1] |
PIN-HOOK
|
|
| 7. |
XKBP-00153
|
[1] |
PIN-JOINT
|
|
| 8. |
XKBP-00154
|
[1] |
PIN-JOINT
|
|
| 9. |
XKBP-00155
|
[1] |
PIN-LOCK
|
|
| 10. |
XKBP-00133
|
[1] |
RING-SNAP
|
|
| 11. |
XKBP-00156
|
[3] |
RING-SNAP
|
|
| 12. |
XKBP-00157
|
[2] |
BOLT-HEX
|
|
| 13. |
XKBP-00158
|
[4] |
NUT-HEX
|
|
| 14. |
XKBP-00015
|
[6] |
NIPPLE-GREASE
|
|
| 15. |
XKBP-00159
|
[2] |
HOSE ASSY
|
|
| 16. |
XKBP-00160
|
[1] |
ELBOW-90
|
|
| 17. |
XKBP-00019
|
[2] |
O-RING
|
|
| 18. |
XKBP-00161
|
[2] |
O-RING
|
|
| 19. |
XKBP-00021
|
[1] |
SPRING
|
|
| 20. |
XKBP-00162
|
[1] |
PIN-SPRING
|
|
| 21. |
XKBP-00023
|
[1] |
STOPPER
|
|
| 22. |
XKBP-00024
|
[1] |
NIPPLE-GREASE
|
|
| 23. |
XKBP-00163
|
[1] |
PIN-STOPPER
|
|
| 24. |
XKBP-00257
|
[1] |
PIN-SNAP
|
|
| 25. |
XKBP-00165
|
[1] |
WIRE ASSY
|
|
