现代零件查询R55-7A QUICK CLAMP ASSY(HOOK TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
330 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-95610
|
[1] |
QUICK CLAMP ASSY
|
|
| 1. |
XKBN-00367
|
[1] |
BODY ASSY
|
|
| 1. |
XKBN-00612
|
[1] |
BODY ASSY
|
|
| 2. |
XKBN-00366
|
[1] |
HITCH ASSY
|
|
| 2. |
XKBN-00613
|
[1] |
HITCH ASSY
|
|
| 3. |
XKBN-00365
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBN-00543
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBN-00614
|
[1] |
CYLINDER ASSY
|
|
| 4. |
XKBN-00042
|
[1] |
PIN-SAFETY
|
|
| 5. |
XKBN-00043
|
[1] |
PIN-SNAP
|
|
| 6. |
XKBN-00357
|
[1] |
WIRE ASSY
|
|
| 7. |
XKBN-00358
|
[1] |
PIN-HITCH
|
|
| 7. |
XKBN-00390
|
[1] |
PIN-HITCH
|
|
| 8. |
XKBN-00359
|
[2] |
BOLT-HEX
|
|
| 8. |
XKBN-00359
|
[1] |
BOLT-HEX
|
|
| 9. |
XKBN-00360
|
[2] |
BUSHING-HITCH
|
|
| 10. |
XKBN-00364
|
[1] |
PIN-FRAME
|
|
| 11. |
XKBN-00049
|
[1] |
PIN-CYLINDER
|
|
| 11. |
XKBN-00392
|
[1] |
PIN-CYLINDER
|
|
| 11. |
XKBN-00610
|
[1] |
PIN-CYLINDER
|
|
| 12. |
XKBN-00050
|
[1] |
RING-SNAP
|
|
| 12. |
XKBN-00336
|
[1] |
RING-SNAP
|
|
| 13. |
XKBN-00051
|
[1] |
LATCH WITH SPRING
|
|
| 14. |
XKBN-00052
|
[1] |
PIN-SPRING
|
|
| 15. |
XKBN-00062
|
[2] |
PIN-BRACKET
|
|
| 16. |
XKBN-00362
|
[2] |
BOLT-HEX
|
|
| 17. |
XKBN-00064
|
[4] |
NUT-HEX
|
|
| 18. |
XKBN-00055
|
[2] |
HOSE ASSY-0X0
|
|
| 19. |
XKBN-00056
|
[2] |
ELBOW-90
|
|
| 20. |
XKBN-00009
|
[4] |
NIPPLE-GREASE
|
|
| 21. |
XKBN-00065
|
[3] |
WASHER-SPRING
|
|
| 22. |
XKBN-00109
|
[2] |
RING-SNAP
|
|
