纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (610-01-1[1]) - HYD LINES, ARM 1.87M (6FT 2IN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
831 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT01V00032F1 | [1] | BUCKET CYLINDER | KOBCylinder Assy, Bucket [ See(C.P.M) ] |
| . . | YT12B00122F1 | [1] | Cylinder Instal | |
| A1. | YT12B01020P1 | [1] | PIN | KOB |
| A2. | HS18C12100G2 | [1] | SCREW | KOBCap |
| A3. | ZN18C12010 | [2] | NUT | KOB |
| A4. | B16T0442D54 | [1] | SHIM,52mm ID x 80mm OD x 0.5mm Thk | KOB |
| A5. | B16T0442D41 | [1] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOB |
| A6. | B16T0442D25 | [1] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| A7. | B16T0442D23 | [1] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOB(1. 6) |
| A8. | YR12B01028P1 | [2] | SHIM | KOB(2. 0) |
| . . | LF43H00013F1 | [1] | Hyd Lines, Arm | |
| B1. | YT43H01013DJ | [2] | FLEXIBLE HOSE | KOB |
