| . . | 24100J6412F2 | [1] | ARM ASSY | |
| 6. | 2419P1722 | [1] | PIN | KOB |
| 7. | 2419P1709D1 | [1] | PIN | KOB |
| 8. | 2419P1710D1 | [1] | PIN | KOB |
| 9. | 2419T3752 | [2] | PIN | KOB Superseded by part number: 2419T7605D1 |
| 11. | 2419P1566D1 | [1] | PIN | KOB |
| 12. | 2418T17376 | [1] | RIGID TUBE | KOB |
| 13. | ZX56N12135 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: ZX56T12135 |
| 16. | ZG91S02000 | [4] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight, Serial Range: YQ0101-YQ0106 |
| . . | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight, Start Serial: YQ0107 |
| 17. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 18. | ZG91V02000 | [3] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT, Serial Range: YQ0101-YQ0106 Superseded by part number: 72283072 |
| . . | ZG91V02000 | [2] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT, Start Serial: YQ0107 Superseded by part number: 72283072 |
| 21. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 22. | ZS13C16130 | [1] | SCREW | KOB |
| 23. | 2420T4330D2 | [3] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 24. | ZS13C10070 | [8] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 25. | ZS13C16140 | [2] | SCREW | KOBM16x2.0x140mm |
| 26. | ZS13C10050 | [1] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 29. | ZN12C16013 | [12] | NUT | KOBM16x2.0mm |
| 31. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 32. | 2432T1187 | [1] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 40. | 2420R349D076 | [1] | HOSE,6.30 mm ID x 760.00 mm, SAE 100R7 | KOB760mm Long (29-59/64 in) Superseded by part number: HX21E04076DX |
| 41. | 2420R349D192 | [1] | HOSE | KOB Superseded by part number: 2420R349D195 |
| 42. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 44. | ZC47X10009 | [1] | CLIP | KOB Superseded by part number: ZC48X10009 |
| 45. | ZC45X10009 | [2] | CLIP | KOB Superseded by part number: ZC46X10009 |
| 46. | ZN11C06005 | [3] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 47. | ZW22X06000 | [3] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 48. | 2411J2788F1 | [1] | ARM | ARM |
| 48-21. | 2405T1274 | [2] | BUSHING,80mm ID x 95mm OD x 93mm L | KOB Superseded by part number: 2405T1902 |
| 48-22. | B05T0041C2 | [2] | BUSHING | KOB |
| 48-23. | B05T0009C2 | [2] | BUSHING | KOB |
| 48-24. | 2418T17497 | [1] | SPACER | KOB |
| 48-25. | 2418T17498 | [1] | SPACER | KOB |
| 49. | 2406N802F1 | [1] | LINK, BUCKET, Serial Range: YQ0101-YQ0114 | LINK, BUCKET, Serial Range: YQ0101-YQ0114 |
| 49-8. | 2405T951 | [2] | BUSHING | KOB |
| 49-9. | 2405T1275 | [2] | BUSHING | KOB |
| 50. | 2445R372D1 | [2] | DUST CAP | KOB |
| 51. | 2445R372D2 | [10] | DUST CAP | KOBSEAL |
| 52. | 2444Z2002 | [3] | HYD CONNECTOR | KOB1/8"PTx1/4"PFx32mm Long |
| 53. | 2418T12144 | [1] | RIGID TUBE | KOB |
| 54. | 2406P3913D1 | [1] | LINK CONROD | KOB |
| 55. | 2406P3913D2 | [1] | LINK CONROD | KOB |
| 56. | 2438U995F1 | [1] | CYLINDER, BUCKET | CYLINDER, BUCKET |
| 57. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 58. | B16T0442D4 | [4] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 59. | B16T0442D37 | [1] | SHIM,155mm OD x 87mm ID x 1.6mm Thk | KOBID 87 x OD 155 x Th 1.6mm |
| 67. | 2406N819F1 | [1] | CHAIN | KOB, Start Serial: YQ0115 |
| 67-8. | 2405T951 | [2] | BUSHING | KOB |
| 67-9. | 2405T1275 | [2] | BUSHING | KOB |
