神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (08-006) - FAN ASSY, AUTOMOBILL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
187 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1794F1 | [1] | FAN, AUTOMOBILE ASSY | FAN, AUTOMOBILE ASSY |
| 1. | 2474U101F2 | [1] | FAN | KOBAUTOMOBILL Superseded by part number: 2474U101F2M |
| 2. | 2416T20741 | [1] | BRACKET | KOB |
| 3. | ZS31C06016 | [4] | SCREW,Phillips Drive, Pan HD, M6 x 16mm | KOBM06x1.0x16mm |
| 5. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 6. | 2479Z849 | [1] | SWITCH | KOBTOGGLE Superseded by part number: 2479Z514 |
| 7. | 2479Z992D2 | [1] | HARNESS | KOB |
| 8. | 2479Z976D3 | [1] | WIRE HARNESS | KOB |
| 9. | 2479Z1441D2 | [1] | HARNESS | KOB |
| 10. | 2432Z309D2 | [3] | CLAMP | KOB |
