凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (88.100.55[11]) - KIT, ULTRASONIC LEVEL, 4 TANK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
277 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47721959
|
[1] |
SENSOR
|
SAS
Assy, Incl 2 - 9
|
| 2. |
47699586
|
[3] |
BRACKET
|
SAS
Ultrasonic to Lid
|
| 3. |
47672797
|
[3] |
BRACKET
|
SAS
Ultrasonic Sensor
|
| 4. |
47625039
|
[4] |
SENSOR
|
SAS
Ultrasonic level
|
| 5. |
BER43139
|
[6] |
|
NUT
|
| 6. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
47837377
|
[1] |
BRACKET
|
SAS
Aux Tank Ultrasonic Sensor
|
| 8. |
86521606
|
[4] |
FLANGE NUT,Hex, 3/8" - 16, Gr 5
|
NH
|
| 9. |
87413269
|
[2] |
U-BOLT
|
SAS
|
