神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (01-001) - FRAME ASSY. UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1010 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13832F2 | [1] | FRAME ASSY. UPP | |
| 6. | 2406T3203 | [1] | BRACKET | |
| 7. | 2420T6786 | [1] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| 8. | 2420R561D1 | [1] | DIPSTICK | KOB |
| 9. | 2420P1519D1 | [1] | PIPE | KOB |
| 10. | ZS13C10025 | [7] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 11. | ZS23C20055 | [12] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 12. | ZS13C20110 | [30] | CAPSCREW | KOBSCREW M20x2.50x110mm |
| 13. | 2420T4564D1 | [3] | BOLT | KOBReamer -- M20x2.50x110mm |
| 14. | ZW13H10000 | [7] | WASHER | KOBID 11 x OD 24 x Th 3.2mm Superseded by part number: ZW16H10000 |
| 15. | ZW13H20000 | [33] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 17. | 2414T4703F1 | [1] | COVER | KOB |
| 17-1. | 2414P7583 | [1] | COVER | |
| 17-2. | 2427Z1343 | [1] | FOAM INSULATION | KOB |
| 19. | 2420T6787 | [10] | SCREW,M12 x 1.75 x 20mm | KOBM12x1.75x20mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12030 |
| 20. | 2427Z1392 | [1] | INSULATION, SOUND | INSULATION, SOUND |
| 21. | 2427Z1391 | [1] | FOAM INSULATION | KOB |
| 22. | 2427Z1393D1 | [1] | FOAM INSULATION | KOB |
| 23. | 2427Z1393D2 | [1] | FOAM INSULATION | KOB |
| 24. | 2427T919D1 | [1] | FOAM INSULATION | KOB |
| 25. | 2427T917D1 | [1] | FOAM INSULATION | KOB |
| 26. | 2479R1805 | [1] | INSULATOR SOUND | INSULATOR SOUND |
| 27. | 2479Z2216 | [1] | INSULATOR | KOB |
| 28. | 2479Z2218 | [1] | INSULATOR | KOB |
| 29. | 2479Z2407 | [1] | INSULATOR | KOB |
| 30. | 2418T12125 | [1] | PLATE | KOB Superseded by part number: YN52F01159P1 |
| 31. | 2416Z434 | [1] | PACKING | KOBRubber |
| 32. | 2414T4850F2 | [1] | COVER ASSY | KOB |
| 32-1. | 2427Z1344 | [1] | FOAM INSULATION | KOBSOUND |
| 32-2. | 2416Z263D2 | [1] | FOAM INSULATION | KOBSHEET, RUBBER |
| 32-3. | 2414P8769 | [1] | COVER | |
| 33. | 2422J3755 | [1] | FRAME, UPP | |
| 33-1. | ZS83C20020 | [1] | SCREW | KOBSet -- M20x2.50x20mm |
| 33-2. | 2405T1256 | [2] | BUSHING | KOB |
| 33-3. | 2414T2784 | [1] | COVER | KOBID 95 X OD 146.4 x Th 06mm |
| 34. | 24100P3750F1 | [1] | STAY | KOBSTAY ASSY |
| 34-1. | 2416P18523 | [1] | STAY | KOBSTAY |
| 34-2. | 2432T4113D2 | [1] | CLAMP | KOB |
| 34-3. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 34-4. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | 2456R351 | [1] | MIRROR | KOB |
| 36. | 2445T290 | [1] | SEAL | KOB Superseded by part number: YN52F01161P1 |
| 37. | 24100J11091F5 | [1] | MOTOR ASSY, SWING SEE FIGURE 025-01 | MOTOR ASSY, SWING SEE FIGURE 025-01 |
