神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (02-004) - SEAT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
524 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N7702F2 | [1] | SEAT ASSY | |
| 2. | 2448U167F2 | [1] | SEAT ASSY | |
| 3. | 2427N3258 | [1] | STAND | KOB |
| 5. | 2414P8996 | [1] | COVER | |
| 6. | 2448U116F1 | [2] | BELT | KOBSEAT |
| 7. | 2420Z1343 | [1] | GROMMET | KOB |
| 11. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 12. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 13. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 14. | ZW22K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 15. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 16. | 2407U71 | [1] | BELT ASSY, SEAT | BELT ASSY, SEAT |
| 17. | 2420T8240 | [1] | SCREW | KOB |
| 18. | 2418T24771 | [1] | SPACER | KOB |
