纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (025-01[1]) - ENGINE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
237 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02P00011F1 | [1] | Engine Instal | |
| . . | YT02P00010F1 | [1] | ENGINE | KOBAssy (See Fig No. 020-01-1) |
| . . | YT02P00012F1 | [1] | ENGINE | KOBEngine Instal |
| 1. | YT02P01004P1 | [1] | BRACKET | KOB |
| 2. | YT02P01011P1 | [1] | BRACKET | KOB |
| 3. | YT02P01006P1 | [4] | RUBBER MOUNTING | KOB |
| 4. | YT02P01019P1 | [4] | PLATE | KOB |
| 5. | PW01P01022P1 | [4] | WASHER | KOB |
| 6. | HS18C12120G1 | [4] | CAPTIVE WASHER SCREW | KOBCap |
| 7. | ZW16H12000 | [6] | WASHER | KOB |
| 8. | ZN18C12010 | [2] | NUT | KOB |
| 9. | ZM73C10030 | [10] | BOLT,M10x30mm - Course Thread | KOBSems |
| 11. | YT02P01015P1 | [2] | HOSE ASSY. | KOBHose |
| 15. | ZH22X08012 | [2] | HYD CONNECTOR | KOB |
| 17. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBCap |
| 18. | ZS18C08100 | [2] | SCREW,Hex, M8 x 100mm | KOBCap |
| 19. | ZW16P08000 | [4] | WASHER | KOB |
| 21. | YT02P01018P1 | [4] | RUBBER MOUNTING | KOB |
| 22. | HD16P02400G2 | [4] | O-RING | KOBO-ring |
| 23. | PY01P01043D2 | [1] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| 24. | YT02P01016P1 | [1] | Hose, Serial Range: LF05-04001-LF05-04199 | |
| 25. | YA03H01018P1 | [1] | ELEC CONNECTOR | KOBConnector |
| 26. | ZH32X08012 | [2] | 90 ELBOW,Male, 30° Fl, PF 1/2" x PF 3/4", O-Ring | KOB |
| 20. | VI8980756710 | [1] | FILTER ASSY | KOB Superseded by part number: 47544071 |
| 20-1. | VI8980756760 | [1] | ELEMENT | KOBOil E/g Superseded by part number: 87729947 |
