神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-008) - TIMING GEAR CASE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
336 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME081646 | [1] | TIMING GEAR CASE ASSY, Start Serial: 9001- | |
| . . | VAME081555 | [1] | TIMING GEAR CASE ASSY, Serial Range: --8912 | |
| 1-5. | VAME088524 | [1] | TIMING GEAR CASE ASSY M5 ONLY | |
| 1. | VAME013245 | [1] | CASE, TIMING GEAR, Start Serial: 9001- | |
| . . | VAME011655 | [1] | CASE | KOBCASE, TIMING GEAR, Serial Range: --8912 Superseded by part number: VAME013244 |
| . . | VAME088525 | [1] | CASE, TIMING GEAR M5 ONLY | |
| 3. | VAMF472406 | [1] | PIN | KOBPIN, DOWEL 12 |
| 4. | VAMS666136 | [1] | PLUG | KOBCAP, SEALING 22 |
| 5. | VAMH037774 | [1] | CAP | KOBCAP, SEALING 17.2 M5 ONLY |
| 6. | VAME013306 | [1] | OIL SEAL | KOBFR, Start Serial: 8910- Superseded by part number: VAME013384 |
| . . | VAME024156 | [1] | OIL SEAL | KOB, Serial Range: --8909 |
| . . | VAME013306 | [1] | OIL SEAL | KOBM5 ONLY Superseded by part number: VAME013384 |
| 7. | VAME011770 | [1] | GASKET | KOBGEAR CASE FOR SERVICE ONLY Superseded by part number: VAME220852 |
| 8. | VAMF140233 | [9] | BOLT | KOBBOLT, FLANGE 8 X 40 |
| . . | VAMF140237 | [10] | BOLT | KOBBOLT, FLANGE 8 X 60 M5 ONLY |
| 9. | VAMF140235 | [6] | BOLT | KOBBOLT, FLANGE 8 X 50 |
| . . | VAMF140241 | [5] | BOLT | KOBBOLT, FLANGE 8 X 80 M5 ONLY |
| 10. | VAMF140239 | [2] | BOLT,FLANGE BOLT, FLANGE 8 X 70 | BOLT,FLANGE BOLT, FLANGE 8 X 70 |
| . . | VAMF140245 | [2] | BOLT | KOBBOLT, FLANGE 8 X 100 M5 ONLY |
