| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHEAD, CYL CF GN450-810A |
| 2. | VAME031886 | [6] | GUIDE | KOBVALVE INLET |
| 3. | VAME031888 | [6] | GUIDE | KOBVALVE EXH |
| 4. | VAMH002174 | [12] | STUD | KOBEXHUST MANIFOLD M10x33mm Long |
| 6. | VAMS666132 | [6] | CAP | KOBCAP, SEALING 14 |
| 7. | VAMS666138 | [8] | CAP | KOBCAP, SEALING 28 |
| 7A. | VAMS666137 | [6] | CAP | KOBCAP, SEALING 25, Start Serial: 8912- |
| . . | VAMS666138 | [6] | CAP | KOBCAP, SEALING 28, Serial Range: --8911 |
| 8. | VAMS666136 | [11] | PLUG | KOBCAP, SEALING 22 |
| 11. | VAME011012 | [1] | GUIDE | KOBDIRECTOR |
| 13. | VAME013297 | [6] | SEAT, VALVE | KOBINSERT, INLET, Start Serial: 8912- |
| . . | VAME011058 | [6] | SEAT, VALVE | KOBVALVE SEAT INLET, Serial Range: --8911 Superseded by part number: VAME013297 |
| . . | VAME013296 | [1] | VALVE | KOBSEMI-SIZE, Start Serial: 8912- |
| . . | VAME011057 | [1] | INSERT | KOBSEMI-SIZE, Serial Range: --8911 |
| 14. | VAME013188 | [6] | SEAT | KOBINSERT VALVE EXH, Start Serial: 8912- |
| . . | VAME029004 | [6] | SEAT | KOBVALVE SEAT EXH, Serial Range: --8911 Superseded by part number: VAME013188 |
| . . | VAME013187 | [1] | INSERT | KOBSEMI-SIZE, Start Serial: 8912- |
| . . | VAME029005 | [1] | INSERT SEMI-SIZE, Serial Range: --8911 | INSERT SEMI-SIZE, Serial Range: --8911 |
| 17. | VAME011015 | [18] | SCREW | KOBCYL HEAD 14 X 122 |
| 18. | VAME011016 | [7] | BOLT | KOBCYL HEAD 14 X 180 |
| 19. | VAME081541 | [1] | CYLINDER HEAD GASKET | KOB, Start Serial: 8702- |
| . . | VAME081515 | [1] | GASKET CYL HEAD, Serial Range: --8701 | GASKET CYL HEAD, Serial Range: --8701 |
