凯斯零件查询(3380) - PRECISION AIR CART (7/08-12/15) (35.204.BE[02]) - DELUXE AUGER ROTARY VALVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
833 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84583850
|
[1] |
HYDRAULIC VALVE
|
SAS
Deluxe Auger Rotary Incl 2 -
|
| 2. |
47429780
|
[1] |
BODY
|
SAS
Body
|
| 3. |
47429763
|
[1] |
SPOOL
|
SAS
Spool
|
| 4. |
47429770
|
[1] |
CAP
|
SAS
Detent
|
| 5. |
47429772
|
[1] |
COMPRESSION SPRING
|
SAS
Compression
|
| 6. |
87429774
|
[1] |
Steel
|
|
| 7. |
87406
|
[2] |
LOCK PIN,6.35mm OD x 38.1mm L, Slotted
|
WIN
|
| 8. |
87035062
|
[9] |
PLUG,Hex, 1/2"-20 ORB
|
BRR
|
| 9. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 10. |
330344
|
[2] |
45 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
WIN
|
| 11. |
47429777
|
[1] |
SERVICE KIT
|
SAS
Seal Kit
|
