凯斯零件查询(3380) - PRECISION AIR CART (7/08-12/15) (35.525.01) - REAR HITCH HYDRAULIC HOSE OPTION Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
780 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
435414A1
|
[2] |
QUICK MALE COUPLING,1/2"-14 NPTF
|
CAS
Superseded by part number: 87335428
|
| 2. |
51200055
|
[2] |
HYDRAULIC HOSE,0.38" ID x 394.00", SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2
|
FLX
3/8" x 394" fl, 1/2" mpt x 1/2" mpt
|
| 3. |
1994568C1
|
[2] |
COUPLING, QUICK, FEM
|
CAS
1/2" fpt
|
| 4. |
86592083
|
[2] |
DUST CAP
|
ZED
pioneer coupler - 1/2"
|
| 5. |
CC-105
|
[7] |
HOSE CLAMP
|
FLX
for 2 hoses
|
| 6. |
GL-358
|
[1] |
BRACKET
|
FLX
hydraulic hose
|
| 7. |
9706689
|
[7] |
BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5
|
PA
|
| 8. |
88902
|
[7] |
NUT,3/8"-16
|
NH
|
| 100. |
51200107
|
[1] |
HYDRAULIC HOSE,0.50" ID x 384.00", SAE 100R2AT, SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2
|
FLX
1/2" x 384" fl, 1/2" mpt x 1/2" mpt
|
| 100. |
51200108
|
[1] |
HYDRAULIC HOSE,0.50" ID x 432.00", SAE 100R2AT, SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2
|
FLX
1/2" x 432" fl, 1/2" mpt x 1/2" mpt
|
