神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-012) - CONNECTING ROD & BEARING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
646 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME012265 | [6] | CONN. ROD SHELL | KOBM1 ONLY, Start Serial: 8608- |
| . . | VAME012251 | [6] | CONN ROD, ASSY M1 ONLY, Serial Range: --8607 | CONN ROD, ASSY M1 ONLY, Serial Range: --8607 |
| . . | VAME012265 | [6] | CONN. ROD SHELL | KOBM5 ONLY |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONROD, CONNECTING |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, CONN-ROD |
| 3. | VAME012232 | [12] | SPECIAL BOLT | KOB |
| 4. | VAME023570 | [12] | NUT | KOB |
| 5. | VAME012234 | [6] | BUSHING | KOB |
| 6-7. | VAME999726 | [1] | BEARING SET | KOBONE MODEL STD Superseded by part number: VAME995170 |
| . . | VAME999727 | [1] | BEARING SET | KOBCONN-ROD BEARING, ONE MODEL US 0.25 Superseded by part number: VAME995171 |
| . . | VAME999728 | [1] | BEARING SET | KOBONE MODEL Superseded by part number: VAME995172 |
| . . | VAME999729 | [1] | BEARING SET | KOBCONN-ROD, ONE MODEL US 0.75 Superseded by part number: VAME995173 |
| . . | VAME999730 | [1] | BEARING SET | KOBCONN-ROD, ONE MODEL US 1.00 Superseded by part number: VAME995174 |
| 6. | VAME013285 | [6] | BEARING, CONN-ROD UPPER STD M1 ONLY, Start Serial: 9002- | |
| . . | VAME012259 | [6] | BEARING, CONN-ROD UPPER STD M1 OLNY, Serial Range: --9001 | |
| . . | VAME013285 | [6] | BEARING, CONN-ROD UPPER STD M5 ONLY | |
| 7. | VAME013287 | [6] | BEARING, CONN-ROD LOWER STD M1 ONLY, Start Serial: 9002- | |
| . . | VAME012210 | [6] | METAL STD BEARING, CONN-ROD LOWER STD M1 ONLY, Serial Range: --9001 | METAL STD BEARING, CONN-ROD LOWER STD M1 ONLY, Serial Range: --9001 |
| . . | VAME013287 | [6] | BEARING, CONN-ROD LOWER STD M5 ONLY | |
