纽荷兰零件查询(65B) - MOTORGRADERS (A1.05[002]) - PISTON New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
898 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4791474 | [6] | PISTON | LEC+0.0 Superseded by part number: 1930186 |
| 2. | 4791477 | [6] | PISTON | LEC+0.4 Superseded by part number: 1930188 |
| 3. | 4791479 | [6] | PISTON | LEC+0.8 |
| 4. | 1930191 | [6] | SET OF RINGS | MODPISTON RING,+0.0 |
| 5. | 4770627 | [6] | LOCKING RING | LECPISTON RING, +0.4 Superseded by part number: 1930193 |
| 6. | 4770629 | [6] | LOCKING RING | LECPISTON RING, +0.8 |
| 7. | 4754401 | [6] | OIL SCRAPER RING | TORPISTON RING, +0.0 |
| 8. | 4770632 | [6] | LOCKING RING | LECPISTON RING,+0.4 Superseded by part number: 1930193, 1930193, 1930210 |
| 9. | 4770634 | [6] | LOCKING RING | LECPISTON RING, +0.8 |
| 10. | 4770449 | [7] | LOCKING RING | LECPISTON RING, +0.0 Superseded by part number: 1930191 |
| 11. | 4770637 | [6] | LOCKING RING | LECPISTON RING, +0.4 Superseded by part number: 1930193 |
| 12. | 4770639 | [6] | LOCKING RING | LECPISTON RING, +0.8 |
| 13. | 4770452 | [12] | SNAP RING,38mm ID | TORLOCKRING |
| 14. | 4770651 | [6] | PISTON PIN | BRE Superseded by part number: 4801851 |
| 15. | 1930186 | [6] | PISTON ASSY | MODKIT, +0.0 |
| 16. | 1930188 | [6] | PISTON ASSY +0.4 | MODKIT, +0.4 |
| 17. | 1930190 | [6] | PISTON ASSY +0.8 | MODKIT, +0.8 Superseded by part number: 4801851, 1930195, 4791479, 4770452 |
| 19. | 1930193 | [6] | SET OF PISTON RINGS +0.4 | MODRING SET, +0.4 |
| 20. | 1930195 | [6] | SET OF PISTON RINGS +0.8 | MODRING SET, +0.8 |
