纽荷兰零件查询(65B) - MOTORGRADERS (A1.05[001]) - PISTONS & CONNECTING RODS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
259 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4706866 | [6] | PISTON | MODSTANDARD Superseded by part number: 1902430 |
| . . | 4706893 | [1] | PISTON | LEC+0.1MM(.004'') |
| . . | 4706894 | [1] | PISTON ASSY +0.2 | MODPISTON,+0.2MM(.008"") |
| . . | 4706895 | [1] | PISTON | LEC+0.4MM(.016"") Superseded by part number: 1901396 |
| . . | 4706896 | [1] | PISTON ASSY +0.6 | MODPISTON,+0.6MM(.024"") Superseded by part number: 1909439 |
| . . | 4706897 | [1] | PISTON | LEC+0.8MM(.031'') Superseded by part number: 1901397 |
| 2. | 4679272 | [6] | LOCKING RING | LECRING, STANDARD |
| . . | 4707725 | [1] | PISTON RING | LECRING,+0.1MM(.004"") |
| . . | 4707726 | [1] | SET OF RINGS | MODRING, +0.2MW. 008"") |
| . . | 4707727 | [1] | LOCKING RING | LECRIN6,+0.4MM(.016'') |
| . . | 4707728 | [1] | SET OF PISTON RINGS +0.6 | MODRING, +0.6MW. 024"") |
| . . | 4707729 | [1] | SET OF PISTON RINGS +0.8 | MODRIN6,+0.8MM(.031"") |
| 3. | 4679227 | [6] | OIL SCRAPER RING | MODRING, STANDARD |
| . . | 4690501 | [1] | OIL SCRAPER RING +0.1 | MKTRING,+0.1MM(.004'') |
| . . | 4690502 | [1] | OIL SCRAPER RING +0.2 | MODRING, +0.2MM(. 008"") |
| . . | 4690503 | [1] | LOCKING RING | LECRING,+0.4MM(.016"") |
| . . | 4690504 | [1] | OIL SCRAPER RING +0.6 | MODRING, +0.6MMC. 024"") |
| . . | 4690505 | [1] | OIL SCRAPER RING +0.8 | MODRING,+0.8MM(.031"") Superseded by part number: 1909250, 1909250, 1930009 |
| 4. | 4679226 | [6] | OIL SCRAPER RING | MODRING, STANDARD |
| . . | 4690496 | [1] | LOCKING RING | LECRING,+0.1MM(.004"") |
| . . | 4690497 | [1] | OIL SCRAPER RING +0.2 | MODRING, +02MM(. 008"") |
| . . | 4690498 | [1] | LOCKING RING | LECRING,+0.4MM(.016"") |
| . . | 4690499 | [1] | OIL SCRAPER RING +0.6 | MODRING,+0.6MM(.024'') |
| . . | 4690500 | [1] | OIL SCRAPER RING +0.8 | MODRING,+0.8MM(.031"") |
| 5. | 4679224 | [6] | PISTON PIN | MODPIN Superseded by part number: 4799077 |
| . . | 4690489 | [1] | PISTON PIN +0.2 | MODPIN,+0.2MM<.008"") Superseded by part number: 4799078 |
| . . | 4690490 | [1] | PISTON PIN +0.5 | MODPIN,+0.5MM(.020"") Superseded by part number: 4799079 |
| 6. | 11059375 | [12] | LOCKING RING | MKTRING Superseded by part number: 11059376 |
| 7. | 4679221 | [6] | CONNECTING ROD | MKTROD, PUSH Superseded by part number: 4763919 |
| 8. | 4762000 | [12] | BOLT | MODBOLT |
| 9. | 4698677 | [12] | BEARING HALF | MODBEARING, STANDARD Superseded by part number: 1901609 |
| . . | 4698678 | [1] | SET OF MAIN BRGS -0.254 | MODBEAR ING,-0.102MM(. 004"") Superseded by part number: 4698730 |
| . . | 4698679 | [1] | BEARING HALF | LECBEARING,-0.254MM(.010"") Superseded by part number: 1901610 |
| . . | 4698680 | [1] | BEARING HALF | LECBEARING, -0.508MM( .020"") Superseded by part number: 1901611 |
| . . | 4698681 | [1] | SET OF MAIN BRGS -0.762 | MODBEARING,-0.762MM(.030"") Superseded by part number: 1901612 |
| . . | 4698682 | [1] | BEARING HALF | LECBEARING,-1 ,016MM( ,040'') Superseded by part number: 1901613 |
| 10. | 4696722 | [12] | BUSHING | MOD Superseded by part number: 4754066 |
