久保田零件查询T06300 FRONT WHEEL HUB FRONT AXLEEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
631 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6659114980
|
[2] |
SHIM DIFF.SIDE
|
0.0110(lbs); 0.005
|
| 010. |
6659114990
|
[2] |
SHIM DIFF.SIDE
|
0.0044(lbs); 0.002
|
| 010. |
6712156630
|
[2] |
SHIM DIFF.SIDE
|
0.0110(lbs); 0.005
|
| 020. |
6712156640
|
[2] |
SHAFT
|
2.1560(lbs); 0.980
|
| 030. |
6373317150
|
[2] |
SEAL OIL
|
0.0880(lbs); 0.040
|
| 050. |
6712156650
|
[2] |
GEAR BEVEL
|
0.8360(lbs); 0.380
|
| 060. |
0810106305
|
[2] |
BEARING BALL
|
0.5060(lbs); 0.230
|
| 070. |
0461200250
|
[4] |
CIR CLIP EXTERNAL
|
0.0044(lbs); 0.002
|
| 080. |
6712156710
|
[2] |
GEAR BEVEL
|
0.7700(lbs); 0.350
|
| 090. |
6712156720
|
[2] |
SHAFT BEVEL GEAR
|
1.6060(lbs); 0.730
|
| 100. |
6712156730
|
[2] |
COLLAR SUPPORT
|
0.1650(lbs); 0.075
|
| 110. |
0461200250
|
[2] |
CIR CLIP EXTERNAL
|
0.0044(lbs); 0.002
|
| 120. |
0810106303
|
[2] |
BEARING BALL
|
0.2464(lbs); 0.112
|
| 130. |
6712156760
|
[4] |
BEARING BALL
|
0.0000(lbs); 0.000
|
| 130. |
6712156770
|
[4] |
BEARING BALL
|
0.2794(lbs); 0.127
|
| 140. |
0461100520
|
[4] |
CIR CLIP INTERNAL
|
0.0198(lbs); 0.009
|
| 150. |
0481110250
|
[2] |
O RING
|
0.0022(lbs); 0.001
|
| 160. |
6712156740
|
[4] |
SEAL OIL
|
0.0352(lbs); 0.016
|
| 170. |
6722156750
|
[2] |
GEAR BEVEL
|
1.2760(lbs); 0.580
|
| 180. |
0810106007
|
[2] |
BEARING BALL
|
0.3520(lbs); 0.160
|
| 190. |
6712156810
|
[2] |
GEAR BEVEL
|
4.4000(lbs); 2.000
|
| 200. |
6715656820
|
[4] |
COLLAR SET
|
0.0088(lbs); 0.004
|
| 210. |
6740156830
|
[2] |
HUB FRONT WHEEL
|
3.6520(lbs); 1.660
|
| 220. |
6620456840
|
[2] |
COLLAR
|
0.0440(lbs); 0.020
|
| 230. |
0810106305
|
[2] |
BEARING BALL
|
0.5060(lbs); 0.230
|
| 240. |
0810106206
|
[2] |
BEARING BALL
|
0.4290(lbs); 0.195
|
| 250. |
6675856970
|
[12] |
BOLT STUD
|
0.0660(lbs); 0.030
|
| 260. |
0401350120
|
[12] |
WASHER PLAIN
|
0.0154(lbs); 0.007
|
| 270. |
0451250120
|
[12] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 280. |
0217450120
|
[12] |
NUT
|
0.0220(lbs); 0.010
|
