神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-020) - EXHAUST MANIFOLD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
583 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-3. | VAME088485 | [1] | EXHAUST MANIFOLD | KOBASSY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONMANIFOLD, EXH |
| 3. | VAMH002174 | [4] | STUD | KOBEXHUST MANIFOLD M10x33mm Long |
| 5. | VAME013536 | [6] | GASKET | KOB Superseded by part number: VAME014349 |
| . . | VAME013518 | [6] | GASKET | KOB, Start Serial: 8512- Superseded by part number: VAME014349 |
| 6. | VAMH004054 | [12] | NUT | KOBNUT, FLANGE 10, Serial Range: --8511 Superseded by part number: 134868A1 |
