纽荷兰零件查询(65B) - MOTORGRADERS (A1.15[001]) - AUXILIARY DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
638 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4607682 | [1] | SUPPORT | |
| . . | 14327101 | [1] | PLUG,M7, Tapered | MKT7MM Superseded by part number: 16987501 |
| . . | 16043921 | [3] | BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8 | TTFCAPSCREH.M8X1.25X35MM Superseded by part number: 16625734 |
| . . | 11198071 | [3] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 2. | 4607586 | [2] | | BRE Superseded by part number: 2981117, 2981117, 4788087 |
| 3. | 4667452 | [2] | WASHER,37.1mm ID x 55mm OD x 1.5mm Thk | TOR |
| 4. | 4676820 | [1] | SPINDLE | MODGEAR Superseded by part number: 4751151 |
| 5. | 4619405 | [1] | SEAL | MOD Superseded by part number: 4858091 |
| 6. | 4607593 | [1] | SUPPORT | MKT Superseded by part number: 4788084 |
| . . | 16044521 | [1] | SCREW,Hex, M8 x 65mm, Cl 8.8 | FORCAPSCREH,M8X1.25X65MM Superseded by part number: 16606424 |
| . . | 16043821 | [2] | SCREW,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd | BASBOLT, Hex, M8 x 30, 8.8 Superseded by part number: 16605724 |
