纽荷兰零件查询(65B) - MOTORGRADERS (A1.16[001]) - FUEL INJECTION PUMP DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
317 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 13401675 | [1] | LOCKING RING | MKTRING, RETAINING Superseded by part number: 13401673 |
| 3. | 14165470 | [1] | LOCK PIN,M5 x 10, Slotted | TTFPIN, LOCK, M5 x 10, Slotted Superseded by part number: 412663 |
| 4. | 4660062 | [1] | GEAR | MKT Superseded by part number: 4751087 |
| 5. | ------------------- | [1] | INCLUDES ITEMS 5-7 GEAR | |
| 7. | ------------ | [6] | NOT SERVICED RIVET,10x42MM | |
| . . | 4607665 | [1] | GASKET | MODNOT SERVICED |
| 9. | 4640558 | [1] | GEAR | MODCOUPLING |
| 10. | -------------- | [1] | INCLUDES ITEMS 10,11 SLEEVE | |
| 11. | ------------- | [1] | NOT SERVICED SHAFT | |
| 12. | 4670937 | [2] | BUSHING | MOD Superseded by part number: 4601834 |
| . . | 4601834 | [2] | BUSHING,49.73mm ID x 54.18mm OD x 16.99mm L | MOD |
| 13. | 4607663 | [1] | SUPPORT | MOD |
| 14. | 4604833 | [1] | SEALING WASHER | MODSLEEVE Superseded by part number: 4809425 |
| 15. | 4667498 | [1] | WASHER | FORHASHER |
| 16. | 11069375 | [1] | LOCKING RING | MKTRING, RETAINING Superseded by part number: 11069376 |
| 17. | 16043421 | [6] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M8 x 20, 8.8 Superseded by part number: 16043424 |
| . . | 11198071 | [6] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
