纽荷兰零件查询(65B) - MOTORGRADERS (A1.16[002]) - INJECTION PUMP DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
546 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4785077 | [1] | SHAFT | LEC |
| 2. | 4769712 | [1] | UNIVERSAL JOINT | MODCOUPLING |
| 3. | 4770452 | [1] | SNAP RING,38mm ID | TORRING, RETAINING |
| 4. | 4769422 | [1] | GEAR | BRE |
| 5. | 4769424 | [1] | SUPPORT | BRE |
| 6. | 4769427 | [2] | BUSHING | FOR |
| 7. | 4769429 | [1] | GASKET | MOD Superseded by part number: 4858092 |
| 8. | 4798845 | [8] | BOLT,M8 x 1.25 x 16.50mm | TOR |
| 9. | 4604833 | [1] | SEALING WASHER | MOD Superseded by part number: 4809425 |
| 10. | 4667498 | [1] | WASHER | FOR |
| 11. | 4708213 | [1] | RING | FORRETAINING |
| 12. | 10519601 | [6] | WASHER,8.15mm ID x 17mm OD x 2mm Thk | BHB Superseded by part number: 17094914 |
| 13. | 13421376 | [1] | SNAP RING,M30, Int | BASRING, SNAP, M30, Int |
| 14. | 16043621 | [6] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | CASHex, M8 x 25, 8.8 Superseded by part number: |
