现代零件查询R75-7 ARM CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
195 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01742
|
[1] |
ARM CYLINDER ASSY
|
|
| 2. |
XJDH-02315
|
[1] |
TUBE ASSY-CYLINDER
|
|
| 3. |
XJDH-02316
|
[1] |
PISTON ROD ASSY
|
|
| 4. |
XJDH-02317
|
[1] |
HEAD-CYLINDER
|
|
| 5. |
XJDH-02318
|
[1] |
BUSHING
|
|
| 6. |
XJDH-02319
|
[1] |
PACKING-ROD
|
|
| 7. |
XJDH-02320
|
[1] |
RING-BACK UP
|
|
| 8. |
XJDH-02321
|
[1] |
SEAL-DUST
|
|
| 9. |
XJDH-02322
|
[2] |
O-RING
|
|
| 10. |
XJDH-02323
|
[3] |
RING-BACK UP
|
|
| 11. |
XJDH-02324
|
[1] |
O-RING
|
|
| 12. |
XJDH-02325
|
[1] |
RING-BUFFER
|
|
| 13. |
XJDH-02326
|
[1] |
RING-SNAP
|
|
| 14. |
XJDH-02327
|
[1] |
COLLAR-CUSHION
|
|
| 15. |
XJDH-02328
|
[1] |
COLLAR
|
|
| 16. |
XJDH-02329
|
[1] |
STOPPER
|
|
| 17. |
XJDH-02330
|
[1] |
PLUNGER
|
|
| 18. |
XJDH-02331
|
[1] |
SEAL
|
|
| 19. |
XJDH-02332
|
[1] |
PISTON
|
|
| 20. |
XJDH-02135
|
[1] |
RING-WEAR
|
|
| 21. |
XJDH-02333
|
[1] |
RING-PISTON
|
|
| 22. |
XJDH-02334
|
[1] |
O-RING
|
|
| 23. |
XJDH-02310
|
[1] |
SCREW-SET
|
|
| 24. |
XJDH-01743
|
[1] |
PACKING ASSY
|
|
| 25. |
XJDH-02335
|
[1] |
PIN-BUSHING
|
|
| 26. |
XJDH-02336
|
[1] |
PIN-BUSHING
|
|
| 27. |
XJDH-02337
|
[4] |
SEAL-DUST
|
|
| 28. |
XJDH-00377
|
[1] |
NIPPLE-GREASE 90
|
|
| 29. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
