现代零件查询R75-7 BUCKET CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01744
|
[1] |
BUCKET CYLINDER ASSY
|
|
| 2. |
XJDH-02338
|
[1] |
TUBE ASSY-CYLINDER
|
|
| 3. |
XJDH-02339
|
[1] |
PISTON ROD ASSY
|
|
| 4. |
XJDH-02340
|
[1] |
HEAD-CYLINDER
|
|
| 5. |
XJDH-02341
|
[1] |
BUSHING
|
|
| 6. |
XJDH-02342
|
[1] |
PACKING-ROD
|
|
| 7. |
XJDH-02343
|
[1] |
RING-BACK UP
|
|
| 8. |
XJDH-02344
|
[1] |
SEAL-DUST
|
|
| 9. |
XJDH-02345
|
[1] |
O-RING
|
|
| 10. |
XJDH-02346
|
[1] |
RING-BACK UP
|
|
| 11. |
XJDH-02347
|
[1] |
O-RING
|
|
| 12. |
XJDH-02348
|
[1] |
RING-BUFFER
|
|
| 13. |
XJDH-02349
|
[1] |
RING-SNAP
|
|
| 14. |
XJDH-02350
|
[1] |
PISTON
|
|
| 15. |
XJDH-02351
|
[1] |
RING-WEAR
|
|
| 16. |
XJDH-02352
|
[1] |
RING-PISTON
|
|
| 17. |
XJDH-02353
|
[1] |
O-RING
|
|
| 18. |
XJDH-02310
|
[1] |
SCREW-SET
|
|
| 19. |
XJDH-01745
|
[1] |
PACKING ASSY
|
|
| 20. |
XJDH-02336
|
[2] |
PIN-BUSHING
|
|
| 21. |
XJDH-02337
|
[4] |
SEAL-DUST
|
|
| 22. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
| 23. |
XJDH-00377
|
[1] |
NIPPLE-GREASE 90
|
|
