现代零件查询R75-7 SWING CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
835 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01746
|
[1] |
SWING CYLINDER ASSY
|
|
| 2. |
XJDH-02354
|
[1] |
TUBE ASSY-CYLINDER
|
|
| 3. |
XJDH-02355
|
[1] |
PISTON ROD ASSY
|
|
| 4. |
XJDH-02356
|
[1] |
HEAD-CYLINDER
|
|
| 5. |
XJDH-02292
|
[1] |
BUSHING
|
|
| 6. |
XJDH-02293
|
[1] |
PACKING-ROD
|
|
| 7. |
XJDH-02294
|
[1] |
RING-BACK UP
|
|
| 8. |
XJDH-02295
|
[1] |
SEAL-DUST
|
|
| 9. |
XJDH-02296
|
[1] |
O-RING
|
|
| 10. |
XJDH-02297
|
[1] |
RING-BACK UP
|
|
| 11. |
XJDH-02298
|
[1] |
O-RING
|
|
| 12. |
XJDH-02300
|
[1] |
RING-SNAP
|
|
| 13. |
XJDH-02306
|
[1] |
PISTON
|
|
| 14. |
XJDH-02136
|
[1] |
RING-WEAR
|
|
| 15. |
XJDH-02308
|
[1] |
RING-PISTON
|
|
| 16. |
XJDH-02309
|
[1] |
O-RING
|
|
| 17. |
XJDH-02310
|
[1] |
SCREW-SET
|
|
| 18. |
XJDH-01747
|
[1] |
PACKING ASSY
|
|
| 19. |
XJDH-02311
|
[1] |
PIN-BUSHING
|
|
| 20. |
XJDH-02357
|
[1] |
PIN-BUSHING
|
|
| 21. |
XJDH-02312
|
[4] |
SEAL-DUST
|
|
| 22. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
