凯斯零件查询(3445) - PRECISION AIR CART (11/15-) (44.520.AB[12]) - REAR AXLE DUAL WHEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
500 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47503828
|
[1] |
SPACER
|
SAS
2", Incl 2 - 4
|
| 2. |
47685718
|
[1] |
SPACER
|
SAS
2"
|
| 3. |
47685770
|
[10] |
BOLT
|
SAS
|
| 4. |
87613300
|
[10] |
WASHER,0.94" ID x 1.75" OD x 0.18" Thk
|
BRR
|
| 5. |
47655317
|
[10] |
NUT
|
SAS
|
| 6. |
47522603
|
[2] |
RIM
|
SAS
38" Dia x 28" W, 10 Hole, White Superseded by part number: 47897661
|
| 7. |
395448
|
[2] |
VALVE STEM
|
ZED
Superseded by part number: 86507333
|
| 8. |
PL
|
[2] |
PROCURE LOCALLY
|
BAS
800/70R38
|
