凯斯零件查询(3445) - PRECISION AIR CART (11/15-) (55.302.AH[01]) - BATTERY MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
539 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47547043
|
[1] |
MOUNT
|
SAS
Battery Tray
|
| 2. |
51200136
|
[2] |
BATTERY BOX
|
FLX
Incl 3 - 4 Superseded by part number: ZQC120171001
|
| 3. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
Battery Box Lid, Incl in 2
|
| 5. |
9804258
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 6. |
86629542
|
[8] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 7. |
56687
|
[1] |
BOLT,Hex, M24 x 180mm, Cl 8.8
|
SAS
|
| 8. |
589418
|
[1] |
LOCK NUT,M24 x 3, Cl 8
|
BER
|
