现代零件查询R75-7 TRAVEL PILOT VALVEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
373 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01753
|
[1] |
PILOT VALVE ASSY
|
|
| 2. |
XJDH-02396
|
[4] |
SHIM
|
|
| 3. |
XJDH-02397
|
[4] |
SHIM
|
|
| 4. |
XJDH-02398
|
[2] |
SHEET
|
|
| 5. |
@
|
[4] |
SPOOL
|
|
| 6. |
@
|
[4] |
SLEEVE
|
|
| 7. |
@
|
[2] |
COVER
|
|
| 8. |
@
|
[4] |
PUSHER
|
|
| 9. |
@
|
[1] |
BODY
|
|
| 10. |
XJDH-02399
|
[4] |
SPRING-COMP
|
|
| 11. |
XJDH-02400
|
[1] |
PLATE
|
|
| 12. |
XJDH-02401
|
[4] |
SPRING-COMP
|
|
| 13. |
XJDH-02422
|
[4] |
SHIM
|
|
| 14. |
XJDH-02402
|
[4] |
SHIM
|
|
| 15. |
@
|
[2] |
CAM
|
|
| 16. |
XJDH-02403
|
[2] |
BOOT
|
|
| 17. |
@
|
[2] |
PIN
|
|
| 18. |
@
|
[6] |
PLUG
|
|
| 19. |
XJDH-00132
|
[2] |
BOLT-SOCKET HEAD
|
|
| 20. |
XJDH-00113
|
[4] |
FLANGE-BOLT
|
|
| 21. |
XJDH-00232
|
[4] |
SCREW
|
|
| 22. |
XJDH-00247
|
[4] |
WASHER
|
|
| 23. |
XJDH-00304
|
[4] |
PIN
|
|
| 24. |
@
|
[4] |
BALL-STEEL
|
|
| 25. |
@
|
[6] |
BALL-STEEL
|
|
| 26. |
XJDH-00326
|
[4] |
O-RING
|
|
| 27. |
XJDH-00328
|
[6] |
O-RING
|
|
| 28. |
XJDH-00336
|
[4] |
O-RING
|
|
| 29. |
XJDH-02404
|
[4] |
PUSHER ASSY
|
|
