现代零件查询R75-7 UPPER FRAME PIPING 1EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
164 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00457
|
[2] |
CONNECTOR-MALE
|
|
| 2. |
XJDH-00334
|
[2] |
O-RING
|
|
| 3. |
XJDH-00485
|
[1] |
ADAPTER-90,LONG,O-RING
|
|
| 4. |
XJDH-00334
|
[1] |
O-RING
|
|
| 5. |
XJDH-00617
|
[1] |
HOSE(P1)
|
|
| 6. |
XJDH-00689
|
[1] |
HOSE(P2)
|
|
| 7. |
XJDH-00688
|
[9] |
HOSE(P3)
|
|
| 8. |
XJDH-01240
|
[2] |
TEE-FLANGE
|
|
| 9. |
XJDH-00337
|
[2] |
O-RING
|
|
| 10. |
XJDH-00386
|
[3] |
PLUG
|
|
| 11. |
XJDH-00328
|
[3] |
O-RING
|
|
| 12. |
XJDH-00977
|
[1] |
TEE
|
|
| 13. |
XJDH-00334
|
[1] |
O-RING
|
|
| 14. |
XJDH-01718
|
[1] |
TUBE ASSY-SUCTION
|
|
| 15. |
XJDH-00344
|
[1] |
O-RING
|
|
| 16. |
XJDH-00072
|
[4] |
BOLT
|
|
| 17. |
XJDH-00280
|
[4] |
WASHER
|
|
| 18. |
XJDH-01715
|
[1] |
HOSE
|
|
| 19. |
XJDH-00529
|
[4] |
BAND-HOSE
|
|
| 20. |
XJDH-01716
|
[1] |
SPRING
|
|
