现代零件查询R75-7 UPPER FRAME PIPING 2EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
1018 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00412
|
[2] |
TEE
|
|
| 2. |
XJDH-00336
|
[2] |
O-RING
|
|
| 3. |
XJDH-00478
|
[1] |
ELBOW-MALE 90,O-RING
|
|
| 4. |
XJDH-00479
|
[4] |
ELBOW-MALE 90,O-RING
|
|
| 5. |
XJDH-01377
|
[2] |
LINE FILTER ASSY
|
|
| 6. |
XJDH-01378
|
[2] |
ELEMENT
|
|
| 7. |
XJDH-00372
|
[1] |
ELBOW-MALE 90
|
|
| 8. |
XJDH-00401
|
[2] |
BUSHING
|
|
| 9. |
XJDH-00407
|
[1] |
ELBOW
|
|
| 10. |
XJDH-00402
|
[1] |
BUSHING
|
|
| 11. |
XJDH-00439
|
[1] |
TEE
|
|
| 12. |
XJDH-00070
|
[3] |
BOLT
|
|
| 13. |
XJDH-00280
|
[3] |
WASHER
|
|
| 14. |
XJDH-01150
|
[1] |
PIPE-RETURN(A)
|
|
| 15. |
XJDH-00535
|
[1] |
HOSE
|
|
| 16. |
XJDH-00571
|
[2] |
BAND-WIRE
|
|
| 17. |
XJDH-00633
|
[1] |
HOSE(1)
|
|
| 18. |
XJDH-00632
|
[1] |
HOSE(T2)
|
|
| 19. |
XJDH-00631
|
[1] |
HOSE(2)
|
|
| 20. |
XJDH-00634
|
[1] |
HOSE(T3)
|
|
