| 1. |
25025083
|
[2] |
CYLINDER ASSY.
|
GFD
2-1/2" x 8" Hyd., See Figure 35.100.04
|
| 2. |
25030242
|
[2] |
CYLINDER ASSY.
|
GFD
3" x 24" Hyd., See Figure 35.100.05 Superseded by part number: 47582264
|
| 2. |
25035241
|
[2] |
CYLINDER ASSY.
|
GFD
3-1/2" x 24" Hyd., See Figure 35.100.08 Superseded by part number: 47575804
|
| . . |
25335242R
|
[2] |
REMAN-HYD CYLINDER
|
GFD
4100 II,4200 II All are in -1990;Reman For New P/N 25035241 Superseded by part number: 47575804R
|
| . . |
25335242C
|
[1] |
CORE-HYD CYLINDER
|
GFD
Return Number
|
| 3. |
25035162
|
[1] |
CYLINDER ASSY.
|
GFD
3-1/2" x 16" Hyd., See Figure 35.100.07 Superseded by part number: 87423782
|
| 4. |
25040242
|
[2] |
CYLINDER ASSY.
|
GFD
4" x 24" Hyd., See Figure 35.100.06 Superseded by part number: 87458679
|
| 5. |
25600642
|
[2] |
HYDRAULIC HOSE,0.38" ID x 42.00", SAE 100R17
|
GFD
|
| 6. |
25600670
|
[2] |
HYDRAULIC HOSE,0.38" ID x 68.00", SAE 100R17
|
GFD
|
| 7. |
25600681
|
[4] |
HYDRAULIC HOSE,0.38" ID x 121.00", SAE 100R17
|
GFD
|
| 8. |
25600695
|
[4] |
HYDRAULIC HOSE,0.38" ID x 220.00", SAE 100R17
|
GFD
|
| 9. |
25600683
|
[2] |
3/8" Hyd. x 275" Long
|
|
| 10. |
25600893
|
[2] |
1/2" Hyd. x 215" Long
|
|
| 11. |
02400127
|
[2] |
|
|
| 12. |
04633200
|
[1] |
TUBE
|
GFD
Lift - Single Lift Wheels
|
| 12. |
04633300
|
[1] |
RIGID TUBE
|
GFD
Lift - Tandems Lift Wheels
|
| 13. |
09503000
|
[2] |
CLAMP
|
GFD
Lift Tube
|
| 14. |
09504000
|
[2] |
CLAMP
|
GFD
Lift Tube
|
| 15. |
22530601
|
[3] |
HOSE CLAMP
|
DMI
|
| 16. |
25405003
|
[2] |
CONTROL VALVE
|
GFD
Throttle - Purple Restrictor
|
| 17. |
25405009
|
[1] |
CONTROL VALVE
|
GFD
Throttle Valve - Yellow Restrictor
|
| 18. |
25705601
|
[2] |
ELBOW
|
GFD
9/16 SAEM X 3/4 JICM 90° Superseded by part number: 86512938
|
| 19. |
25705602
|
[2] |
9/16 SAEM X 3/8 NPTF 90°
|
|
| 20. |
25707510
|
[2] |
HYD CONNECTOR
|
GFD
1/2 NPTM X 3/4 JICM Superseded by part number: 76352
|
| 21. |
25707518
|
[2] |
3 WAY CONNECTION
|
GFD
3/4 JICM Superseded by part number: 128996
|
| 22. |
25707521
|
[4] |
ELBOW
|
GFD
3/4 JICM X 3/4 SAEM 90° Superseded by part number: 128830
|
| 23. |
25707522
|
[4] |
3 WAY CONNECTION
|
GFD
(2) 3/4 JICM X 3/4 SAEM Superseded by part number: 86513024
|
| 24. |
25707524
|
[2] |
3/4 SAEM X 7/8 JICM 90°
|
|
| 25. |
25705005
|
[2] |
FITTING
|
GFD
Main Cyl. Cross
|
| 26. |
25708808
|
[2] |
ADAPTER
|
GFD
7/8 JICM X 1/2 NPTM
|
| 27. |
25708815
|
[2] |
REDUCER FITTING
|
GFD
1/2 NPTF X 3/8 NPTM
|
| 28. |
25800010
|
[3] |
CYLINDER
|
DMI
Stroke Control Kit 1-1/4"
|
| 29. |
30007000
|
[14] |
CABLE TIE,.350" x 20.9"
|
DMI
CABLE STRAP 24" Plastic
|
| 30. |
NSS
|
[3] |
NOT SOLD SEPARAT
|
CON
5/16" NC Hex. Nut
|
| 32. |
14816264
|
[2] |
CLEVIS PIN
|
GFD
1" x 3" EL (Hardened) Superseded by part number: 25890100
|
| 33. |
14816346
|
[2] |
1" x 4-1/4" EL
|
|
