神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-060) - FUEL RETURN SYSTEM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
278 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAMS602013 | [5] | FLEXIBLE HOSE | KOBHOSE, FUEL 6 X 110 Superseded by part number: VAMS602013A |
| 2. | VAMS602035 | [1] | HOSE HOSE, FUEL 6 X 220 M0 ONLY | HOSE HOSE, FUEL 6 X 220 M0 ONLY |
| . . | VAMS602073 | [1] | HOSE,6mm ID x 410mm L | KOBHOSE, FUEL 6 X 410 M5 ONLY |
| 3. | VAMS660163 | [13] | CLAMP | KOBCLIP, HOSE 11.6 Superseded by part number: VA0531771160 |
| 4. | VAME019612 | [1] | PIPE B FUEL LEAK OFF | PIPE B FUEL LEAK OFF |
| . . | VAME018087 | [1] | PIPE | KOBFUEL LEAK OFF M5 ONLY |
| 5. | VAME016571 | [1] | CAP | KOB |
| 6. | VAMH020801 | [1] | CLIP | KOBCLIP M0 ONLY, Start Serial: 8604- |
| . . | VAMH020255 | [1] | CLIP M0 ONLY, Serial Range: --8603 | |
| . . | VAMH020135 | [1] | CLIP | KOBCLIP M5 ONLY |
| 7. | VAMH000999 | [1] | BOLT | KOBBOLT, FLANGE 6 X 12 M0 ONLY, Start Serial: 8604- |
| . . | VAMF140003 | [1] | BOLT | KOBBOLT, FLANGE 6 X 12 M0 ONLY, Serial Range: --8603 |
