神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-059) - FUEL HOSE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME910343 | [1] | HOSE | KOBFUEL FEED, PUMP-FILTER L=430 |
| 2. | VAME910338 | [1] | HOSE | KOBFUEL FEED, FILTER-PUMP L=380 |
| 3. | VA3166103600 | [1] | PROTECTOR | KOBPROTECTOR, RUBBER, Serial Range: --9103 |
| 12. | VA3006155500 | [1] | CLIP | KOBCLAMP CLAMP Superseded by part number: VAMH020280 |
| 13. | VAMF140021 | [1] | SCREW | KOBBOLT, FLANGE 8 X 12 |
| 14. | VAMF434104 | [1] | NUT | KOBNUT, FLANGE 8 |
